D-Link Unied Services Router  5
ENGLISH
The Services Router provides an serial port that
enables a connection to a computer or terminal
for monitoring and conguring the device. This
port is a RJ-45 connector, implemented as a
data communication terminal equipment (DCE)
connection.
To use the console port connection, you need the
following equipment:
1. A terminal or a computer with both a serial port
and the ability to emulate a terminal.
2. A RJ45-to-DB9 RS-232 with female connector.
(Already included in packing list)
3. If your Laptop or PC doesn’t have RS-232
connector, a converter is required.
DSR-150 does not come with RS-232
converter and these must be purchased separately.
To establish a console connection:
1. Plug the RJ-45 connector of the supplied
RJ45-to-DB9 cable directly to the console port
on the Services Router.
2. Connect the other end of the cable to a terminal
or to the serial connector of a computer
running terminal emulation software. Set the
terminal emulation software as following:
115200
8
 None
 1
 None
3. If you correctly set up the terminal, following
previous instructions in section of “Connecting
Power and Turn the Device On/Off” and turn
on the device, the boot sequence should
appear in the terminal.
4. Once the boot sequence completes, the
command prompt is displayed, the device is
ready to be congured.


Additional help is available through D-Link
worldwide ofces listed at the appendix of the User
Manual or online. To know more about D-Link
security product products or marketing information,
please visit the website 
; for any support issue, please visit the website
, which will redirect
you to appropriate local D-Link website.

After setup initialization, you should refer to the
companion publications found in PDF format on
the accompanying master CD for more infor-
mation on how to begin to congure the DSR-150
device.

This document describes the general operation
and control of the Services Router rmware which
drives and controls the Services Router series
hardware. It includes examples of how to carry
out typical administrative tasks such as setting up
a VPN and how to use Services Router series in
various scenarios.

This document describes all log messages that
might be generated by Services Router during
system operation.

This document describes all available text-based
commands that can be used on RJ45-to-DB9
Console or SSH interface to congure Services
Router during system operation.

