10/100 Fast Ethernet Switch Manual
3
♦ Make sure that there is proper heat dissipation from and
adequate ventilation around the Switch. Do not place heavy
objects on the Switch.
Desktop or Shelf Installation
When installing the Switch on a desktop or shelf, the rubber feet
included with the device must be first attached. Attach these
cushioning feet on the bottom at each corner of the device. Allow
enough ventilation space between the device and the objects
around it.
Figure 2.1 10/100 Fast Ethernet Switch installed on a Desktop or
Shelf
Rack Installation
The Switch can be mounted in an EIA standard size, 19-inch rack,
which can be placed in a wiring closet with other equipment. To
install, attach the mounting brackets on the Switch’s front panel
(one on each side) and secure them with the screws provided.
