D-Link DWR-921 Quick Installation Guide

DWR-921 Quick Installation Guide
Default Settings
Domain name of device
dlinkrouter.local.
IP address of device
192.168.0.1
Username (login)
admin
Password
admin
Name of wireless network (SSID)
DWR-921
Network key (PSK)
see WPS PIN on the barcode
label on the bottom panel of
the device
!
Clients connected to the router with default settings do not have access
to the Internet. To get started, please set your own password for access
to the web-based interface and change the WLAN name (SSID); then,
if needed, configure other settings recommended by your ISP.
3

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
