DWR-953 Wireless AC1200 4G LTE Router
with Gigabit Ethernet Ports
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Frequency band From the drop-down list, select a band of the wireless network.
SSID
A wireless network to which the rule will be applied. Select the
needed value from the drop-down list.
Enabled
If the switch is moved to the right, the rule is active.
Move the switch to the left to disable the rule.
MAC address
In the field, enter the MAC address to which the rule will be
applied. You can enter the MAC address of a device connected to
the router's LAN at the moment. To do this, select the relevant
device from the drop-down list (the field will be filled in
automatically).
Upload
Maximum rate
Specify the maximum value of the upstream traffic rate (Mbps) or
move the Not limited switch to the right not to limit the maximum
bandwidth of upstream traffic.
Download
Maximum rate
Specify the maximum value of the downstream traffic rate (Mbps)
or move the Not limited switch to the right not to limit the
maximum bandwidth of downstream traffic.
After specifying the needed parameters, click the SAVE button.
To edit a rule, left-click the relevant rule. In the opened window, change the needed parameters and
click the SAVE button.
To remove a rule, select the checkbox located to the left of the relevant line in the table and click
the DELETE button ( ).
To set a schedule for the bandwidth limitation rule, click the Set schedule icon ( ) in the line
corresponding to this rule. In the opened window, from the Rule drop-down list, select the Create
rule value to create a new schedule (see the Schedule section, page 236) or select the Select an
existing one value to use the existing one. Existing schedules are displayed in the Rule name
drop-down list.
To enable the bandwidth limitation rule at the time specified in the schedule and disable it at the
other time, select the Enable rule value from the Action drop-down list and click the SAVE
button.
To disable the bandwidth limitation rule at the time specified in the schedule and enable it at the
other time, select the Disable rule value from the Action drop-down list and click the SAVE
button.
Page 164 of 264
