DWR-953 Wireless AC1200 4G LTE Router
with Gigabit Ethernet Ports
User Manual
Overview
Specifications
*
Hardware
Processor
· RTL8685PB (1GHz)
RAM
· 128MB, DDR2, built in processor
Flash
· 16MB, SPI
Built-in modem
· BroadMobi BM806U-E1
Interfaces · Slot for SIM card (mini-SIM)
· 10/100/1000BASE-T WAN port
· 4 10/100/1000BASE-T LAN ports
LEDs · POWER
· INTERNET
· 5GHz
· 2.4GHz
· 4G
· 2G/3G
· LAN
· WAN
· SMS
· SIGNAL STRENGTH
Buttons · ON/OFF button to power on/power off
· RESET button to restore factory default settings
· WPS button to set up wireless connection
· WLAN button to enable/disable wireless network
Antenna · Two detachable LTE/3G antennas (3dBi gain)
· Two internal Wi-Fi antennas for 2.4GHz band (3dBi gain)
· Two internal Wi-Fi antennas for 5GHz band (3dBi gain)
MIMO
· 2 x 2
Power connector
· Power input connector (DC)
Software
WAN connection types · Mobile Internet
· PPPoE
· IPv6 PPPoE
· PPPoE Dual Stack
· Static IPv4 / Dynamic IPv4
· Static IPv6 / Dynamic IPv6
· PPPoE + Static IP
· PPPoE + Dynamic IP
· PPTP/L2TP + Static IP
· PPTP/L2TP + Dynamic IP
* The device features are subject to change without notice. For the latest versions of the firmware and relevant
documentation, visit www.dlink.ru.
