SD Card Slot This port can be used to insert an external SD memory card. The maximum
capacity SD card that can be inserted into this port is 32Gb.
Management port (MGMT) This is a 10/100/1000Mbps Out-Of-Band management port that can be used to
configure this switch without being connected to the network.
Console Port This port is an RJ-45 connection port that can be used to connect to the Command
Line Interface (CLI) of this switch for configuration, management and monitoring.
This port uses a special console cable (included with the packing) with a DB9
interface to connect the Switch to a PC’s COM port.
10 Gigabit ports This switch is equipped with SFP/SFP+/WDM ports. These ports can operate at
10Gbps speeds and support a vast collection of SFP/SFP+/WDM transceivers.
Expansion Module Slot This slot can be equipped with several kinds of additional modules. These modules
are not included and should be bought separately:
• DXS-3600-EM-4XT (Four 10GBase-T Copper ports)
• DXS-3600-EM-8T (Eight 1000Base-T Copper ports)
• DXS-3600-EM-4QXS (Four 40Gbps QSFP+ transceiver slots)
• DXS-3600-EM-8XS (Eight 10Gbps SFP+ transceiver slots)
• DXS-3600-EM-Stack (Two 120Gbps CXP Stacking ports)
3
