Section 1 - Product Overview
Hardware Overview - DIR-3060
Back Panel
21 3 4 5 6 7
1 USB 2.0 Port Connect a USB storage device to share les over the network.
2 Gigabit LAN Ports (1- 4)
Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game
consoles.
3 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
4 USB 3.0 Port Connect a USB storage device to share les over the network.
5 Reset Button
Insert a paperclip in the hole, wait for 10 seconds, and release to reset the router to default
settings.
6 Power Connector Connector for the supplied power adapter.
7 Power Button Press the power button to power the device on or o.
