D-Link GO-RT-N300 Quick Install Guide

5
3
Connect another Ethernet cable from the Ethernet port on your computer
to one of the LAN ports on the router. You can also connect wirelessly to
the router with your computer. Complete steps 4 and 5 before attempting
to connect.
4
Plug the power back into your DSL or cable modem. Please wait about
one minute before continuing.
12V 1A
WPS
LAN4 3 12 INTERNET
POWER
RESET
GO-RT-N300
Computer
Ethernet Cable
12V 1A
WPS
LAN4 3 12 INTERNET
POWER
RESET
Modem
GO-RT-N300
Computer
5
12V 1A
WPS
LAN4 3 12 INTERNET
POWER
RESET
Modem
GO-RT-N300
Computer
6
After the router has powered up, verify that the Power and Internet LEDs are
both lit. Proceed with router conguration.
Plug the power adapter into your router and connect to an available
power outlet or surge protector. If the Power LED does not light up, press
the Power button on the back of the router.
If connecting wirelessly, open your wireless utility on your computer and
connect to the router. The Wi-Fi network (SSID) is GO-RT-N300 with no
password.

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
