D-Link Nuclias Connect DAP-3666

Quick Install Guide
This installation guide provides basic
instructions for installing the DAP-3666
Nuclias Connect AC1200 Wave 2 Outdoor
Access Point on your network. For additional
information about how to use the Access
Point, please see the datasheet and user
manual from the D-Link support website.
Minimum System
Requirements
Computer with Windows, MAC OS, or Linux-
based operating system, and an Ethernet
adapter installed
- Mozilla Firefox 52.0 or higher, Internet
Explorer 11 or higher, Safari 10.1 or
higher, Google Chrome 59 or higher.
Package Contents
- DAP-3666 Nuclias Connect AC1200 Wave
2 Outdoor Access Point
- Quick Installation Guide
- Mounting kit (Wall/Pole Mount)
- Stainless steel mount base x 1
- Stainless tie back straps x 2
- Wall screw x 4
- Wall plug x4
- Stainless mount screw (hexagonal hole)
x1
- Hexagon Socket Spanner
- Two LAN Port Waterproof Enclosure
- Grounding Wire
If any of the above items are missing, please
contact your reseller.
NOTE no PSU supplied. To power the units use an
D-Link PoE switch, DPE-311GI or 802.3af PoE adapter.
Physical Installation
STEP 1: Connect an Ethernet
Cable to the LAN1 (PoE) Port on
the AP.
STEP 2: Mount the AP to a Pole
or Wall
2A: Mounting The DAP-3666 On
A Pole
Secure mount base to the pole with two
stainless tie back strap sets. Ensure that the
tie back is locked securely.
Pole Mount
3
