83DSL-2750B User Guide
Before following the steps below, please factory reset the DSL-2750B.
1. Open a web browser and enter http://192.168.1.1.
2. Log in with the default user name (admin) and password (refer to back label of 2750B).
3. Select My Network > Internet.
4. From the drop-down menu next to Connection type, select LAN-WAN Bridged Ethernet Connection
over ATM (Bridged ETHoA).
Multiple Static Public IPs
5. Click Apply.
6. When the following message appears, click OK.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link Verizon DSL-2750B and is the answer not in the manual?

D-Link Verizon DSL-2750B Specifications

General IconGeneral
DSL TechnologyADSL2+
Wi-Fi Standard802.11b/g/n
Wi-Fi Frequency2.4 GHz
Wi-Fi SpeedUp to 300 Mbps
Ethernet Ports4 x 10/100 Mbps
FirewallNAT, SPI
ADSL2+ Downstream Data RateUp to 24 Mbps
ADSL2+ Upstream Data RateUp to 1 Mbps
Device TypeWireless Gateway
USB Ports1 x USB 2.0
SecurityWEP, WPA, WPA2
Weight300 g
