78D-Link DIR-855L User Manual
Section 3 - Conguration
Enter a name for the policy and then click Next to continue.
Select a schedule (i.e., Always) from the drop-down menu and
then click Next to continue.
Enter the following information and then click Next to continue:
• Address Type - Select IP address, MAC address, or
Other Machines.
• IP Address - Enter the IP address of the computer you
want to apply the rule to.
• Machine Address - Enter the PC MAC address (i.e.,
00:00.00.00.00).
Select the ltering method and then click Next to continue.
Note: If you select the Apply Advanced Port Filters option you will
be forwarded to the Add Port Filters Rules window. Otherwise, you
will be advanced to the Congure Web Access Logging window
(see next page).
