8D-Link DAP-1522 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
Bridge LED
A blinking light indicates that the
DAP-1522 is in bridge mode
AP LED
A blinking light indicates that the
DAP-1522 is in AP mode.
Power LED
A solid light indicates a proper connection
to the power supply.
LAN LEDs
A solid light indicates a connection to an
Ethernet-enabled device on ports 1-4. This
LED blinks during data transmission.
WPS LED
A solid light indicates a successful
WPS connection. A blinking light
indicates the device is trying to
establish a connection.
