Hardware Provided - IDEA Panoramic (Multi-Panel)
#8 x ½” Screws
Number of supplied screws
varies by screen size
44” Wall Bracket
See Table 1 for Quantities.
28” Wall Bracket
See Table 1 for Quantities.
Seam Brace
See Table 1 for Quantities.
LBrackets
(4) - 2 Panel Screens
(6) - 3 Panel Screens
1032 Nuts
(4) - 2 Panel Screens
(8) - 3 Panel Screens
Hardware Provided - IDEA Screen (Single Panel)
(7) #8 x ½” Screws
(2) 44” Wall Brackets
(2) LBrackets
Wall Brackets and Seam Braces Included
Item Number Overall Dimensions Panels Wall Brackets Seam Braces
29512 46¾" x 122¾" 2 (4) 28" 1
29513 46¾" x 245¾" 3 (6) 28" 2
29636 50¾" x 89¾" 1 (2) 44" -
29637 50¾" x 170¾" 2 (4) 28" 1
29638 53¾" x 253¾" 3 (6) 28” 2
Table 1
