INSTRUCTION BOOK FOR

Boardroom Electrol

®

Table of Contents

Other manuals for Da-Lite Boardroom Electrol

Specifications2 pages

Questions and Answers:

J
Jamie Collins Jr.Aug 21, 2025
What to do if my Da-Lite Projector Accessories screen will not operate?
- R
  Ryan WilcoxAug 21, 2025
  If your Da-Lite Projector Accessories screen isn't operating and the motor isn't humming, here are a few things to check: * Replace the fuse if it's blown. * Reset the circuit breaker if it's tripped. * Check for power at the operating switch or junction box, and tighten any loose wire connections. * Allow the motor to cool for 15 minutes if the thermal overload has tripped. * Check for continuity if there's a broken wire in the 'down' position. If these steps don't resolve the issue, the motor assembly might need replacing due to a defective motor, limit switch, or capacitor. Also, with the power off, try turning the roller by hand to free any temporary binding. If the capacitor is burned out, you also need to replace the motor assembly.
L
Lynn LewisAug 25, 2025
What to do if Da-Lite Projector Accessories door will not open?
- S
  Steven PalmerAug 25, 2025
  If the door of your Da-Lite Projector Accessories won't open, check the installation to ensure the door can move freely. Clear any foreign substances like paint or plaster from the hinge. Also, adjust the slat hooks. The door can be opened by removing the four screws holding the slat hooks to the door. Access should be provided to these screws during and after installation.
C
Connor IbarraAug 26, 2025
Why is my Da-Lite Projector Accessories fabric hanging crooked?
- E
  Emily RodriguezAug 26, 2025
  If the fabric of your Da-Lite Projector Accessories is hanging crooked, ensure the screen is installed level and plumb. If the fabric has backed up inside the case, adjust the 'down' limit switch slowly until the roller is exposed and the wrinkle comes out, then readjust for proper drop. If the fabric is damaged, consider replacing it.
D
Donna AllenAug 27, 2025
What causes noise in Da-Lite Projector Accessories?
- M
  Michael HughesAug 27, 2025
  If your Da-Lite Projector Accessories is making noise, consider these possibilities: a squeaking sound could be due to the rubber end plug rubbing on the motor, in which case you should center the roller in the case. A grinding sound might indicate a foreign object rubbing on the roller or fabric, which needs to be removed. Gear noise usually means the motor assembly needs to be replaced.
L
Lisa ScottAug 29, 2025
What to do if Da-Lite Projector Accessories door does not close tightly?
- E
  Edward JohnsonAug 29, 2025
  If the door of your Da-Lite Projector Accessories isn't closing tightly, first check if the rubber bumpers are loose and tighten them. If that doesn't work, the door limit switch might not be adjusted properly, so turn the adjustment knob counter-clockwise, being careful not to over-adjust and stall the motor. Also, adjust the black limit switch clockwise (towards +) if the 'up' limit switch in the motor is out of adjustment, causing the motor to shut off too soon and leave the fabric door open.
M
Melanie AtkinsAug 31, 2025
What causes coasting in Da-Lite Projector Accessories?
- T
  Taylor GarrettAug 31, 2025
  Coasting in Da-Lite Projector Accessories is caused by a defective brake. The suggested solution is to replace the motor assembly.
C
Carly HallSep 2, 2025
What causes Da-Lite Projector Accessories fabric door to hang down?
- C
  Caitlin HillSep 2, 2025
  If the fabric door on your Da-Lite Projector Accessories hangs down on one end, check if the rubber bumpers are not tight and tighten them. If the slat hooks are not formed equally, bend the slat hook slightly or apply tape to the end of the slat where the door hangs to build the slat up enough to close the door. If these steps don't correct the issue, and the pocket is crooked, consider replacing the fabric.
A
Aaron MillerSep 3, 2025
What to do if roller displaced from mounting bracket in Da-Lite Projector Accessories?
- K
  Karen HunterSep 3, 2025
  If the roller is displaced from the mounting bracket in your Da-Lite Projector Accessories because the pin end slipped out of the nylon bearing, remove the pin end mounting, realign the motor in the tube, and reattach the pin end.
J
Janet CummingsSep 5, 2025
What to do if my Da-Lite Boardroom Electrol will not go down?
- K
  Kathleen JensenSep 5, 2025
  If your Da-Lite Projection Screen isn't operating or going down, and the motor is either silent or humming, there are several potential causes: * A blown fuse: Replace the fuse. * A tripped circuit breaker: Reset the circuit. * No power to the operating switch or junction box: Check the power supply. * Insufficient line voltage: Ensure it's at least 115V or 220V, depending on the motor type; correct if necessary. * Thermal overload: Allow the motor to cool for 15 minutes before trying again. * Broken wire in the 'down' position: Tighten loose wire connections and recheck wiring, referring to the installation instructions. * Defective motor, limit switch, or capacitor: Replace the motor assembly. * Burned-out capacitor: Replace the motor assembly.
R
Rhonda JonesSep 6, 2025
What to do if my Da-Lite Projection Screen will not move upward?
- G
  gcolemanSep 6, 2025
  If your Da-Lite Projection Screen won't move upward and the motor is either silent or humming, consider these potential causes: * Blown fuse: Replace the fuse. * Tripped circuit breaker: Reset the circuit breaker. * No power to the operating switch or junction box: Check the power supply. * Insufficient line voltage: Ensure it's at least 115V or 220V, depending on the motor type; correct if necessary. * Open door micro switch: Replace the micro switch. * Thermal overload: Let the motor cool down for 15 minutes before trying again. * Broken wire in the 'up' position: Tighten all loose wire connections. * Defective motor, limit switch, or capacitor: Replace the motor assembly. * Capacitor burned out: Replace the motor assembly.

Da-Lite Boardroom Electrol Specifications

General

Brand	Da-Lite
Model	Boardroom Electrol
Category	Projection Screen
Language	English
