Instruction Book for

CONTOUR

®

ELECTROL

®

Table of Contents

Questions and Answers

J
Julie WarrenAug 16, 2025
Why is my Da-Lite Contour Electrol making noise?
- S
  sarabryanAug 16, 2025
  If your Da-Lite Projection Screen is making excessive noise (other than a low hum), it could be due to several reasons. Squeaking might be from the rubber end plug rubbing on the motor, which can be resolved by centering the roller in the case. Grinding sounds or other noises could indicate a foreign object rubbing on the roller or fabric. It may also be gear noise. In these cases, replacing the motor assembly might be necessary.
W
williamsgraceAug 22, 2025
What to do if my Da-Lite Projection Screen has incorrect stopping position in downward direction?
- S
  Shannon MooreAug 22, 2025
  If your Da-Lite Projection Screen stops at the wrong position when moving downwards, it could be due to a lost roller wrap or a misadjusted 'down' limit switch. Refer to the provided instructions for information on how to solve this issue.
B
Brenda GardnerAug 27, 2025
What to do if my Da-Lite Contour Electrol Projection Screen has incorrect stopping position in upward direction?
- M
  Melissa RussellAug 28, 2025
  If your Da-Lite Projection Screen stops at the wrong position when moving upwards, it could be due to a lost roller wrap or a misadjusted 'up' limit switch. Adjust the 'up' limit switch. Additional information may be available by calling for assistance.
R
Ryan GonzalezSep 2, 2025
Why does my Da-Lite Contour Electrol keep coasting?
- M
  Marissa PerezSep 2, 2025
  If your Da-Lite Projection Screen is coasting, it means the brake is defective and you should replace the motor assembly.
C
Casey HudsonNov 9, 2025
What to do if my Da-Lite Projection Screen will not operate and the motor doesn't hum?
- K
  kristi53Nov 9, 2025
  If your Da-Lite Projection Screen isn't working and the motor is silent, here's what to check: * **Voltage:** Ensure the voltage is between 115-125V (or 220-240V). If it's too low, rewire the incoming electrical line. * **Fuse/Breaker:** Replace any blown fuses and reset tripped circuit breakers. * **Wiring:** Check for loose or incorrect wire connections and tighten or correct them. For the down position, verify power across the black and white leads; for the up position, check the red and white leads. Also, the thermal overload may have tripped. Allow the motor to cool for 15 minutes before trying again. Check for broken wires in the up or down positions by checking for continuity and reconnecting any cut splices. If these steps don't solve the issue, the motor assembly, limit s...

Summary

Installation Methods

Wall Mount Installation

Instructions for securely attaching the screen case to a wall.

Ceiling Flush Mount Installation

Procedure for flush mounting the screen case directly to a ceiling.

Ceiling Hook Mount Installation

Steps for mounting the screen case using ceiling hook brackets.

Electrical Installation

Junction Box and Testing Procedures

Guidance on opening the junction box, making connections, and testing.

Screen Limit Adjustment

120 V Screens Limit Adjustment

Detailed steps for setting up/down limit switches for 120V screens.

220 V;240 V Screens Limit Adjustment

Procedure for adjusting limit switches on 220V/240V screens.

Wiring Diagrams for Contour Electrol

120 V Wiring Diagram

Diagram illustrating standard wiring for 120V Contour Electrol screens.

120 V Wiring with Video Projector Interface

Wiring diagram for 120V models with optional projector interface.

240 V Wiring Diagram

Diagram showing standard wiring connections for 240V models.

240 V Wiring with Video Projector Interface

Wiring diagram for 240V models including projector interface.

Troubleshooting and Maintenance

Restoring Lost Roller Wrap

Step-by-step guide to fix a screen where the fabric has lost its roller wrap.

Warranty Information

Limited Five Year Warranty Details

Overview of the five-year limited warranty for Contour Electrol products.
