Instruction Book for

DESIGNER ELECTROL®

The Da-Lite Difference.

Table of Contents

Other manuals for Da-Lite DESIGNER ELECTROL

Specifications2 pages

Questions and Answers

M
Margaret StevensAug 13, 2025
Why is my Da-Lite Projection Screen so noisy?
- R
  Randall GonzalezAug 13, 2025
  If your Da-Lite Projection Screen is making excessive noise, consider the following: * **Rubber End Plug:** The squeaking might be due to the rubber end plug rubbing on the motor. Adjust the roller to center it within the case. * **Foreign Object:** A grinding sound could mean there's something stuck between the screen and the roller or fabric. Remove any foreign objects. * **Gear Noise:** If it sounds like gear noise, the motor assembly may need to be replaced.
L
Linda PriceAug 19, 2025
Why is my Da-Lite DESIGNER ELECTROL Projection Screen coasting?
- P
  Patrick ValenzuelaAug 19, 2025
  If your Da-Lite Projection Screen continues to move after you've stopped it, the brake is likely defective. Replacing the motor assembly should resolve this issue.
K
Kyle PattersonAug 25, 2025
How to fix a Da-Lite DESIGNER ELECTROL roller displaced from mounting bracket?
- T
  Timothy HartAug 25, 2025
  If the roller of your Da-Lite Projection Screen has come out of the mounting bracket, it's likely that the pin end has slipped out of the nylon bearing. To fix this, remove the pin end mounting, realign the motor within the tube, and then re-attach the pin end.
P
Paul NelsonSep 2, 2025
Why Da-Lite Projection Screen is coasting?
- O
  oalvarezSep 2, 2025
  If your Da-Lite Projection Screen is coasting, the cause may be a defective brake. Replace the motor assembly.
J
Jeremy HamiltonNov 7, 2025
What to do if my Da-Lite Projection Screen will not operate?
- S
  Stephen CraigNov 8, 2025
  If your Da-Lite Projection Screen isn't working, and the motor isn't making any noise, here's what to check: * **Voltage:** Ensure the incoming electrical line provides 115-125V (or 220-240V). Rewire if needed. * **Fuse:** Replace the fuse if it's blown. * **Circuit Breaker:** Reset the circuit breaker if it has tripped. * **Wiring:** Check for power at the operating switch or junction box. Tighten any loose wire connections and correct improper connections. Use a multimeter to check for power across the black and white leads in the 'down' position, and across the red and white leads in the 'up' position. If the motor hums, but the screen still won't move: * **Thermal Overload:** Let the motor cool down for about 15 minutes and try again. * **Broken Wire:** Check for continu...
E
ernest49Nov 27, 2025
What to do if my Da-Lite DESIGNER ELECTROL will not move up?
- P
  paulblackwellNov 28, 2025
  If your Da-Lite Projection Screen isn't moving up, and the motor either doesn't hum or does hum, consider the following possible causes: * Blown fuse: Replace the fuse. * Tripped power supply circuit breaker: Reset the circuit breaker. * No power to operating switch or junction: Check for power, tighten any loose wire connections, and correct improper connections. For the “Up” position, check for power across the red and white leads. * Thermal overload tripped: Allow the motor to cool down for 15 minutes. Then, try again. * Broken wire in the "up" position: Check for continuity, cut off the old splice, and reconnect. * Defective motor: Replace the motor assembly. * Temporary binding: With power off, turn the roller by hand to free the binding. * Motor burned out: Replace t...

Summary

Important Safety Instructions

General Safety Precautions

Basic safety precautions for operating video equipment, including reading instructions.

Cord Safety and Handling

Guidelines for positioning power cords to prevent tripping or contact with hot surfaces.

Extension Cord Usage Guidelines

Recommendations for selecting and using extension cords with the appliance.

Pre-Installation Procedures

Unpacking and Handling

Instructions for safely unpacking the screen and handling it in an upright position.

Mounting Method Overview

Description of available mounting methods: wall and ceiling.

Case and Surface Dimensions

Details on case extension beyond the picture surface and slat attachment.

Designer Electrol Installation

Wall Mounting Instructions

Step-by-step guide for installing the screen on a wall, including hardware.

Ceiling Mounting Instructions

Step-by-step guide for hanging the screen from the ceiling using anchor points.

120 V Wiring Diagram

Diagram illustrating the electrical connections for 120V operation.

240 Volt Wiring Diagram

Wiring diagram for standard wall switch operation with 240 volt screens.

Screen Travel Adjustment

Procedure for adjusting the limit switches to set screen drop positions.

Troubleshooting Guide

Screen Operation Issues

Solutions for screen not operating or motor humming, including voltage and wiring checks.

Limit and Roller Adjustments

Correcting stopping positions and restoring lost roller wrap for screen fabric.

Noise and Mechanical Faults

Troubleshooting noise, coasting, and roller displacement issues.
