Programming > Pump Start Up
Once you have installed the ACTIVE DRIVER and the pump is primed and ready to start, these
are the simple steps to programming the controller.
After switching the power supply on, the following indication should be present,
ZF = Zero Flow & General Reset
Shortly after, the ACTIVE DRIVER should switch to the following condition and the pump
should start.
Go = Pump Operating
It should then stop after demand has ceased and now display,
Sb = Pump Waiting (Standby)
The pump is now idle and waiting for demand pressure to drop in order to start.
Programming > Inputting Data
The ACTIVE DRIVER is pre programmed and will operate the pump with out any additional
programming, but for most efficient operation, settable parameters are offered to optimal
performance of the system.
The AD M/T and AD T/T will need information about the pump to be inputted before safe
operation can begin.
The settable parameters are as follows,
SP >SET POINT , is the desired operating pressure of the system.
To access this setting, press [mode] and [set] simultaneously for two seconds, the
display should indicate
SP , and then flash to 3.0 which is the pre set of 3.0 Bar.
This can be changed in Bar from a minimum setting of 1.0 up to 6.0 in the AD M/M 1.1,
and 9.0 in all other models. Using the [+] or [-] keys will lift or lower the setting.
Once the setting has been made, pressing [set] will return the indication to the
operating mode of the system (Go or Sb)
rC >RATED CURRENT , is specific to the pump being used (not
applicable to AD M/M 1.1).
To access this setting, press [mode], [set] and [-] simultaneously for five seconds, the
display should indicate
rC , and then flash to 0.0 which is the pre set. This should
be changed to reflect the correct current of the pump being used. (Check compliance
plate or call 1300783601 if unsure). Inputting the wrong information here can damage
the pump. This setting will not appear when programming the AD M/M 1.1.
Once the setting has been made, pressing the [mode] key will move the display to the
next settable parameter, pressing [set] will return the indication to the operating mode
of the system (Go or Sb)
