DIGITAL INDICATOR
DN500N
12
Ⅴ. STEP 5
This span is to display the calculated Span constant.
If indicator displays this condition, it means Span calculation is finished.
If constant value is between 0.50000~1.50000, span is normally calibrated.
If constant value is not between 0.50000~1.50000, you need to do the Span
calibration once again so that you can use the scale with better accuracy.
After span constant is displayed, C_End._ will be displayed and slowly
flashing for about 3 seconds to test the condition of display. Then it will
be displayed as “normal operation mode” for measuring.
Now, Span Calibration is completed.
→ When you do setting weight:
When (Value of one division/Max. display capacity) less than 1/5,000,
you need to prepare for a standard weight that is over 10% of Max display division
and then set the value. When it is more than 1/5,000, you need to prepare for a standard
weight that is over 20% of Max display division and then set the value. This is to do the span
calibration with better accuracy.
- If you do the setting a weight over Max display division, an Error Message
“Err 04” will be displayed.
- If you do the setting a weight below 10 % of Max display division,
an Error Message “Error 05” will be displayed.
★★
