DIGITAL INDICATOR
DN500N
15
▶ HOW TO CHANGE SETTING FOR F-Function
To change setting for F-Function, you need to ender the number you want with number Key and
press “ENTER” Key so that it will be saved in the internal Memory and the change is completed.
Please remember if you enter only number Key and don’t press “ENDER” Key the value cannot be
saved.
▶ To change current display “F06-05” to “F06-08”:
① Press “8” Key – “F06-08”
② Presses “ENTER” Key so that it can be saved in the internal memory.
※ You must press “ENTER” Key when the setting value is changed
to the number you want to save the value in the internal memory.
TEST Mode
TEST TEST Mode Title Description
TEST1
Analog TEST Mode
This mode is to test Analogue.
TEST2
Key TEST Mode
This mode is to test front keys.
TEST3
SET.CAL Mode
You can set F-Function or capacity.
TEST4
DISPLAY TEST Mode
This mode is to check if front display is normal.
TEST5
RELAY OUT TEST Mode
This mode is to check if Relay output is normal when
there is RELAY.
TEST6
External Input TEST Mode
This mode is to check if external input is normal.
TEST7
Initial Analogue TEST Mode
This mode is to check the initial analogue value that
is without any weight setting.
TEST8
Setting DATA Printer Output TEST
Mode
This mode is to print F-Function setting value by
using printer.
- How to return to the first step - TEST -
You need to press to escape from each mode.
On TEST3 mode, press to return to TEST mode again.
