English 111
Care and maintenance - Cooktop
Grates and wok grate
CAUTION
Do not clean the grates or wok grate in a dishwasher. They will be damaged.
You should wash the grates regularly and
after spillovers. They are not dishwasher-
safe. To clean the grates, wait until they
are cool enough to touch safely, then
remove them from the cooktop, and
wash them with hot, soapy water. Rinse
the grates with clean, and dry them
thoroughly. Reposition the grates securely
as instructed earlier in this manual.
Burner head and cap replacement
Dual Burner head / caps
1. Orient the burner head so the electrode
opening aligns with the electrode itself.
2. Install the burner head so the electrode
passes through its opening in the head.
Verify that the burner head lies flat on
the cooktop.
NY9900M_PRO RANGE_DOP48M96DLM_DG68-00935A-00_EN+MES+CFR.indb 111 2017-05-12 7:29:04
