English 15
Custom Panel Specications
W1 W1
G1
H1
H2
G2
Callout 42”
W1 20 25/32” (528 mm)
H1 49 3/16” (1249 mm)
H2 30 9/16” (776 mm)
G1 5/32” (4 mm)
G2 5/32” (4 mm)
Panel Thickness 3/4” (19 mm)
Do not exceed the max load that the custom panel can endure. Before crafting the panel,
check the strength of the panel’s material and the load of attachments to the panel.
42”
Custom Panel
Maximum Weight
Fridge : 55 lb (25 kg), Freezer : 22 lb (10 kg)
NOTE
• Standard Custom panel thickness is 3/4” (19 mm).
Dacor_T-TYPE_BRF9000M_IM_DA68-03621F-00_EN.indd 15 2017-09-28 3:10:07
