English 17
Attach the handle
WARNING
Follow these instructions to attach the handle. Otherwise, the handle may be damaged or
malfunction.
1. Put the reinforced handle support on the rear of the door panel, and then put the
handle on the front of the door panel.
2. As shown, tighten the 4 screws on each of the upper and the lower sides of the handle.
Do not tighten them excessively.
Panel
Handle
(PW) M4x16
4 ea
Reinf Handle
Dacor_T-TYPE_BRF9000M_IM_DA68-03621F-00_EN.indd 17 2017-09-28 3:10:07
