Dacor DRF42 series User Manual

English 39
Custom Panel: Recessed Back, Other
If, by the nature of its design, the panel cannot be attached at the center of the bracket,
use the whichever suitable screw holes on the sides of the bracket to attach the panel.
UPP : 4 ea / LOW : 4 ea
(FH) M4x14 8 ea
Fridge Door
Freezer/FreshZone+ Door
Front
Back
Screw
1/4”
3/4”
Bracket
Dacor_T-TYPE_BRF9000M_IM_DA68-03621F-00_EN.indd 39 2017-09-28  3:10:15
