Dacor EF36LNBSS - Door Panels and Cabinet Clearance

8
1
/ 4
" (6.35 mm)
3
/ 4 " (1.9 cm)
1" (2.5 cm)
1
/ 2 " (1.3 cm)
3
/
4
"
1
"
1
1
/
4
"
1
1
/
2
"
1
/
2
"
Refrigerator
side trim
Hinge
90° door
stop position
Backer panel
Door
Overlay panel
Door Swing 90˚
Actual Size
Refrigerator to
Cabinetry Clearance
(1.9 cm)
(2.5 cm)
(3.8 cm)
(1.3 cm)
(3.2 cm)
Spacer panel
1
/
2
"
3
/
4
"
1
"
(1.3 cm)
(1.9 cm)
(2.5 cm)
Cabinetry
Installation Requirements
Allow a minimum of 4½” (11.4 cm) of space between the side of the refrigerator and a corner wall. More clearance may be needed if
thicker custom panels or custom handles are used. Do not overlook baseboards.
Refrigerator to
Cabinet Clearance
Door Panels and Cabinet Clearance - IF36 Series Models (cont.)
Door swing 90°
actual size
