Dacor EF36LNBSS - Installation Requirements; Door Panels and Cabinet Clearance - IF36 Series Models

7
Backer panel
Overlay panel
Spacer panel
1
/ 4 " (6.35 mm)
3
/ 4 " (1.9 cm)
1" (2.5 cm)
1
/ 2 " (1.3 cm)
1
"
1
1
/
4
"
1
1
/
2
"
1
"
(2.5 cm)
1
(3.2 cm)
1
/
4
"
1
(3.8 cm)
1
/
2
"
1
/
2
"
Refrigerator
side trim
Door
Hinge
(2.5 cm)
(3.2 cm)
(3.8 cm)
(1.3 cm)
Cabinetry
3
/
4
"
(1.9 cm)
110˚ door
stop position
Installation Requirements
The custom door panels and adjacent cabinets for models series IF36 must be designed so that there is sufficient clearance for the
doors to swing open. If the refrigerator is to be installed close to the wall, see Door Swing 90° on the following page.
When the doors are closed the refrigerator will extend beyond the face of the adjacent cabinet to some degree.
NOTE: For IF36 series models, rout
the hinge side of the custom door
panels to a radius that is equal to at
least half the thickness of the panel
if a 130° door swing is desired. See
Adjust Doors.
Door Panels and Cabinet Clearance - IF36 Series Models
Refrigerator to
Cabinet Clearance
Door swing 110°
actual size
