Product Dimensions
Side View:
The depth from the front of the top grille to the back of the 
refrigeratorcabinetis25³⁄8” (64.5 cm).
The power cord is 84” (213.3 cm) long. 
The water line attached to the back of the refrigerator is 5 ft. 
(1.5 m) long.
Heightdimensionsareshownwithlevelinglegsextended¹⁄ 
8”
(3.2 mm) below the rollers.
* When leveling legs are fully extended to 1¼” (3.2 cm) below
rollers,add1¹⁄
8” (2.9 cm) to the height dimensions.
Top View:
Installation Requirements
Front View:
Width dimensions were measured from trim edge to trim edge. 
Heightdimensionsareshownwithlevelinglegsextended¹⁄  8”
(3.2 mm) below the rollers.
* When leveling legs are fully extended to 1¼” (3.2 cm) below
rollers,add1¹⁄
8” (2.9 cm) to the height dimensions.
Door Swing Dimensions
The location must permit both doors to open to a minimum of
90°. Allow 4½” (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels, custom handles or extended handles on a IF36 model.
To adjust the door swing, see Adjust Doors.
*3 1/2” (8.9 cm)
23 1/2”
(59.7 cm)
25 3/8”
(64.5 cm)
*83 3/8”
(211.8 cm)
84” (213.4 cm)
Power Cord
35 1/4”
(89.5 cm)
25 3/8”
(64.5 cm)
23”
(58.4 cm)
51”
(129.5 cm)
90˚
110˚
130˚
59”
(149.9 cm)
36 1/4” (92.1 cm)
*83 3/8”
(211.8 cm)
