Daedong DK90 - Shuttle Shift Lever; Pto Speed Change Lever; Pto Selection Lever

4-16 DK65/75/80/90
628O425A
Push forward or pull backward to select
forward or reverse. The direction of
travel can be changed without changing
the speed range.
SHUTTLE SHIFT LEVER
(A) Forward (B) reverse
628O426A
PTO SPEED CHANGE LEVER
(1) PTO Change Lever
(A) 540rpm (B) 750rpm
Two PTO speeds can be obtained by
shifting the PTO speed lever from the
operator’s seat.
CAUTION
To avoid personal injury:
Disengage the PTO, stop engine,
and allow all rotating compo-
nents to come to a complete stop
before connecting, disconnec-
ting, adjusting, or cleaning any
PTO dri-ven equipment.
DK65 DK75/80/90
628O427A
You can select independent PTO opera-
tion or ground speed (by transmission
speed ratio) PTO.
To select an operating mode; stop the
tractor completely, reduce the engine
speed to idle, turn PTO clutch switch to
neutral position, depress the clutch pedal
and now select the PTO operating mode.
(1) PTO Selection Lever
(A) Independent PTO
(B) Ground Speed PTO
PTO SELECTION LEVER
DK65 DK75/80/90
