Daedong DK90 - Brake Pedal Adjustment; Brake Oil; Brake Oil Reservoir

6-12 DK65/75/80/90
Refill the brake oil before the fluid level
reaches the lower limit.
BRAKE OIL
628O632A
CAUTION
Always bleed the air from the
brake system after any service
or repair.
Air in the system will make the
brake pedal feel “soft”, and brake
failure is likely to occur.
Never operate the tractor unless
the brake oil is at the proper
level.
Use only DAEDONG approved
brake fluid.
BRAKE PEDAL ADJUSTMENT
628O616A
Brake pedal travel
20 ~ 30 mm
(0.79 ~ 1.18 in.)
from the pedal
(1) Brake Pedal
(A) Pedal Travel
WARNING
When making any brake adjust-
ments, make sure that both pedal
travel and pedal force are equal
for both pedals. Unequal braking
can result in a serious accident.
Brake problems must be cor-
rected immediately for your
safety. Contact your DAEDONG
dealer for assistance.
To adjust brake pedal travel; loosen the
locknut from the clevis that connects the
pedal with the master cylinder, remove
the clevis pin, and turn the clevis to
achieve the desired pedal travel as indi-
cated below. Reassemble and secure the
locknut.
(1) Brake oil reservoir
