5
R920 RF01Y109JA R FUSIBLE 1W 1 OHM J A CURVE
SCT1 4859303530 SOCKET CRT PCS629-03C
SF1 5PG1984M-- FILTER SAW G1984M
SW801 5S40101146 SW POWER PUSH SS-160-7-B
T401 50D10A2--- TRANS DRIVE TD-10A2
T402 50H0000211 FBT 1142.5109
T801 50M3535A1- TRANS SMPS "2074,5046 "
U100 4859720730 TUNER VARACTOR UV1316/A
X502 5XE12R000E CRYSTAL QUARTZ HC-49/U 12.00000MHZ 30PPM
Z501 5PYXT5R5MB FILTER CERA XT5.5MB
ZZ200 PTMPJRA21C6FP PCB MAIN RADIAL AS DTA-21C6TFP
C101 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C102 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3*11) TP
C106 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C120 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C121 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C305 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C313 CMXM2A104J C MYLAR 100V 0.1MF J TP
C320 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C390 CMXM2A473J C MYLAR 100V 0.047MF J TP
C401 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3*11) TP
C412 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
C414 CMXM2A104J C MYLAR 100V 0.1MF J TP
C417 CMXL2E104K C MYLAR 250V 0.1MF K MEU TP
C418 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C420 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C500 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C501 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C502 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C504 CMXM2A332J C MYLAR 100V 3300PF J TP
C509 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C511 CMXB1H224J C MYLAR 50V EU 0.22MF J(TP)
C512 CMXB1H224J C MYLAR 50V EU 0.22MF J(TP)
C513 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C514 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C519 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C522 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C524 CMXM2A104J C MYLAR 100V 0.1MF J TP
C525 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C526 CMXM2A104J C MYLAR 100V 0.1MF J TP
C527 CMXM2A473J C MYLAR 100V 0.047MF J TP
C528 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C530 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C532 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C533 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C537 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C555 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C560 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C564 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C565 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C570 CCXB1H472K C CERA 50V B 4700PF K (TAPPING)
C571 CCXB1H821K C CERA 50V B 820PF K (TAPPING)
C585 CCXB1H222K C CERA 50V B 2200PF K (TAPPING)
C590 CXCH1H270J C CERA 50V CH 27PF J (TAPPING)
LOC. PART CODE PART NAME PART DESCRIPTION
C591 CXCH1H270J C CERA 50V CH 27PF J (TAPPING)
C592 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C593 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C599 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C600 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C601 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C602 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C650 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C770 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C806 CEXF1H330V C ELECTRO 50V RSS 33MF (6.3X11) TP
C807 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
C808 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C820 CCXB3A471K C CERA 1KV B 470PF K (T)
C821 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C824 CCXB3A471K C CERA 1KV B 470PF K (T)
C831 CCXB3A471K C CERA 1KV B 470PF K (T)
C835 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3*11) TP
C844 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C863 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C866 CCXB3A471K C CERA 1KV B 470PF K (T)
C888 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C910 CCXB1H561K C CERA 50V B 560PF K (TAPPING)
C968 CMXL2E104K C MYLAR 250V 0.1MF K MEU TP
CA04 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
CA05 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
Q101 T2SC5343Y- TR 2SC5343Y
Q402 T2SD1207T- TR 2SD1207-T (TAPPING)
Q501 TSTA933Y-- TR STA933-Y
Q502 T2SC5343Y- TR 2SC5343Y
Q503 T2SC5343Y- TR 2SC5343Y
Q510 TSTA933Y-- TR STA933-Y
Q511 TSTA933Y-- TR STA933-Y
Q520 T2SC5343Y- TR 2SC5343Y
Q807 T2SC5343Y- TR 2SC5343Y
Q808 T2SC5343Y- TR 2SC5343Y
Q809 T2SC5343Y- TR 2SC5343Y
Q810 T2SC5343Y- TR 2SC5343Y
Q811 T2SC5343Y- TR 2SC5343Y
SW700 5S50101090 SW TACT SKHV17910A
SW701 5S50101090 SW TACT SKHV17910A
SW702 5S50101090 SW TACT SKHV17910A
SW703 5S50101090 SW TACT SKHV17910A
SW704 5S50101090 SW TACT SKHV17910A
Z603 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z605 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z606 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z630 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
ZZ200 PTMPJAA21C6FP PCB MAIN AXIAL AS DTA-21C6TFP
10 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
20 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
A001 4859804593 PCB MAIN T1.6X246X246 CP-185
LOC. PART CODE PART NAME PART DESCRIPTION
!
R
!
!
R
R
R
SERVICE PARTS LIST
