Daewoo 14C5 - Pin Description; General Description

39
6. 24C08 8 Kbit EEPROM
features :
- 8 Kbit serial I2C bus EEPROM
- Single supply voltage : 4.5 V to 5.5 V
- 1 Million Erase/Write cycles (minimum)
- 40 year data retention (minimum)
Pin description
The memory device is compatible with the I2C memory standard. This is a two wire serial interface that uses a bi-directional
data bus and serial clock. The memory carries a built-in 4-bit unique device type identifier code (1010) in accordance with the
I2C bus definition.
Serial Clock (SCL)
The SCL input is used to strobe all data in and out of the memory.
Serial Data (SDA)
The SDA pin is bi-directional, and is used to transfer data in or out of the memory
7. STR - F6653
7-1. general description
The STR-F6653 is an hybrid IC with a build-in MOSFET and control IC, designed for flyback converter type switch mode power
supply applications.
7-2. features
- Small SIP fully isolated moulded 5 pins package
- Many protection functions :
Pulse-by-pulse overcurrent protection (OCP)
Overvoltage protection with latch mode (OVP)
Thermal protection with latch mode (TSD)
Pin No. Name Description
1, 2, 3 E0, E1, E2 Device address
5 SDA Serial Data/Address Input/Output
6 SCL Serial clock
7 WC Write control
8 Vcc Supply voltage
4 Vss Ground
APPENDIX
IC DESCRIPTION
