PART NAME SPEC QTY LOCATION
DIODE UF203 1 D2
DIODE ZENOR 1N5241B 1 ZD1
DIODE ST01D-200 1 D1
C-CERA 2200pF, 250V 1 CY1
CHOKE COIL 1mH, 0.5A 1 L1
FILTER EMI 0.6*10*3TURN 1 L2
BUZZER BM-20K 1 BZ1
COIL 130uH, 3A 1 L3
IC REGULATOR KIA7805P 1 IC3
TR KRC102M 1 TR1
IC RESET KIA7042P 1 IC5
RELAY US11-12S 2 RL3,4
RELAY UKH-12S 1 RL1
SW TRANS 264P,1916 1 TRS1
CAPACITOR 1uF,400VAC 1 CAP1
PCB CONTROL 162.5X140X1.6T 1 PCB
IC SWITCHING TNY264P 1 IC2
DIODE BRIDGE S1NB80 1 BD1
TRIAC SM3JZ47 1 T1
PHOTO COUPLER TLP560J 1 PT1
IC DRIVE TD62004AP 2 IC4,IC6
RESONATOR CST8.00MGW 1 OSC
IC MICOM TMP87C846AN 1 IC1
PHOTO COUPLER TLP421 2 PC1,PC2
