◆DSB-123A PART LIST (INDOOR UNIT)
PART NAME SPEC QTY LOCATION
FUSE 250V 50T 3.15A 1 FUSE
FUSE CLIP AFC-520 2 FUSE
VARISTOR 15G561K 1 VAR
WAFER YW396-05AVD 1 CN2
WAFER YW396-03AVD 1 CN1
WAFER YW396-03AVD(BL) 1 CN9
C-CERA 104Z,50VDC 5 CC1,2,5,6,7
C-CERA 103Z,50VDC 5 CC3,4,9,10,12
C-MULTI 104Z,CR0561B-Z5U 1 CC8
C-ELEC 470uF 35V SD 1 CE1
C-ELEC 10uF 450V SD 2 CE3,CE4
C-ELEC 100uF 16V SD 1 CE2
C-ELEC 10uF 16V SS 1 CE5
C-ELEC 4.7uF 50V SS 1 CE6
C-ARRAY F3 104Z 1 CA3
C-ARRAY F4 104Z 1 CA2
C-ARRAY F5 104Z 1 CA1
RESISTOR 1/4W-12.7KF 2 R28,29
RESISTOR 1/4W-1KJ 22 R5,12,13,14,15,16,17,18,19,20,21,
R23,30,31,32,33,34,35,36,37,43,44
RESISTOR 1/4W-10KJ 1 R11
RESISTOR 1/4W-5.6KJ 1 R22
RESISTOR 1/4W-330J 2 R25,26
RESISTOR 1/4W-100J 2 R1,R4
RESISTOR 1/4W-68KJ 2 R8,R9
RESISTOR 1/4W-51KJ 1 R6
RESISTOR 1/4W-2KJ 1 R7
RESISTOR 1/2W-1KJ 1 R2
RESISTOR 1W-47J 1 R3
RESISTOR 1/4W-8.45KF 1 R41
RESISTOR 1/4W-11.1KF 1 R39
RESISTOR ARRAY 4A 103J 1 RA3
RESISTOR ARRAY 5A 103J 1 RA2
RESISTOR ARRAY 6A 103J 1 RA1
C-LINE ACROSS 275V 104K 2 CL1,CL2
WAFER SMAW250-06(WHITE) 1 CN6
WAFER SMAW250-08 1 CN5
WAFER YMAW250-04 1 CN7
DIODE 1N4007 TAPE 1 D3
DIODE UF203 1 D2
DIODE ZENOR 1N5241B 1 ZD1
