◆DSB-182PH CONTROL
PART NAME SPEC QTY LOCATION
WAFER SMW250-06(WHITE) 2 CN5,CN6
WAFER SMW250-06(RED) 1 CN4
WAFER SMAW250-10 1 CN1
WAFER SMW250-07 1 CN2
WAFER SMW250-02 1 CN3
WAFER YF254S-02 1 TEST
WAFER 5267-04A 1 CN8
WAFER 5267-02A 1 CN7
DIODE 1N4148 TAPE 1 D1
C-CERA 103Z,50VDC 7 CC3,4,5,6,8,9,10
C-CERA 104Z,25VDC 3 CC1,2,7
C-MULTI 104Z,CR0561B-Z5U 1 CC13
C-ELEC 10uF 16V SS 1 CE2
C-ELEC 4.7uF 50V SS 1 CE1
C-ARRAY F3 104Z 1 CA2
C-ARRAY F5 104Z 1 CA1
RESISTOR 1/4W-12.7KF 3 R18,20,22
RESISTOR 1/4W-10KJ 4 R1,2,16,17
RESISTOR 1/4W-5.6KJ 1 R10
RESISTOR 1/4W-1KJ 16 R3,4,5,6,7,8,9,11,12,13,14,26,32,33,34
RESISTOR 1/4W-330J 3 R19,21,23
RESISTOR OPTION 1/4W 1% 5 * REFER TO RESISTOR OPTION TABLE
FILTER EMI 0.6*10*3TURN 1 F1
RESISTOR ARRAY 4A 103J 1 RA2
RESISTOR ARRAY 6A 103J 1 RA1
PCB CONTROL 110X90.5X1.6T(99) 1
TR KRC 3198Y 1 TR1
TR KRC102M 1 TR2
IC RESET KIA7042P 1 IC2
RESONATOR CST8.00MGW 1 OSC1
IC MICOM TMP87C846AN 1 IC1
IC DRIVE TD62004AP 2 IC3,4
To Next Page
