77
◆DSB-182PH POWER
PART NAME SPEC QTY LOCATION
PIN GP881205-2(187) 1 CN8
PIN GP881206-2(250) 2 CC,CL
FUSE CLIP AFC-520 2 FUSE
FUSE 250V 50T 3.15A 1
WAFER YFW800-01D 1 CN9
WAFER YFW800-02D 1 CN2
WAFER YW396-05AVD(RED) 1 CN1
WAFER YW396-05AVD 1
WAFER YW396-03AVD 1 CN4
WAFER YW396-03AVD(BLUE) 1 CN5
WAFER SMW250-10 1 CN6
WAFER 5281-02A 1 CN7
DIODE 1N4004 TAPE 6 D1,2,3,4,5,6
VARISTOR 15G561K 1 VAR
C-CERA 103Z,50VDC 1 CC4
C-CERA 104Z,25VDC 3 CC1,2,3
C-ELEC 1000uF 35V SD 1 CE1
C-ELEC 470uF 25V SD 1 CE2
C-ELEC 100uF 16V SD 1 CE3
RESISTOR 1/4W-10KJ 1 R2
RESISTOR 1/4W-5.6KJ 1 R3
RESISTOR 1/4W-1KJ 2 R1,6
RESISTOR 1/2W-1KJ 1 R4
RESISTOR 1/4W-100J 1 R5
RESISTOR 1W-120J 1 R7
C-LINE ACROSS 275V 104K 2 C1,C2
BUZZER DP-2520BA 1 BZ1
COIL 130uH 3A 1 L1
RELAY CS11-SH12 4 RL1,2,3,4
TR KRC102M 1 TR1
IC REGULATOR KIA7812P 1 IC1
IC REGULATOR KIA7805P 1 IC2
PCB POWER 130X81X1.6T(84) 1
TRIAC SM3JZ47 1 T1
PHOTO COUPLER TLP560J 1 PT1
