LOCATION OF CONTROLS
OPERATING SECTION
Indoor Cover
Electrostatic Filter
Removes dust
particles from the air.
Deodorizing Filter
Removes bad
smells from the air.
Emergency/
Remote Switch
Slide to select
the desired position.
Indicators
Indicate the
AC setting.
Remote Sensor
Power Plug
Air Cleaning
Filters
Removes dust
and prohibits
germs.
AIR OUT
Air In
Sensor Wire
(Only DSB-182LH/LH-R )
Fan Direction
(Up/Down)
Fan Direction
(Left/Right)
O
N
O
F
F
E
N
T
E
R
C
A
N
C
E
L
T
I
M
E
R
R
E
S
E
T
F
A
N
D
I
R
.
F
A
N
S
P
E
E
D
M
O
D
E
S
L
E
E
P
O
N
/
O
F
F
T
E
M
P
.
LCD Remote Controller
INDOOR UNIT
Connection Cover
Remove cover to access the AC connection
to the indoor unit.
Service Valves
The indoor and outdoor units
are connected by copper tubes
which are connected here.
AIR IN
AIR OUT
OUTDOOR UNIT
