CP-850FX Service Manual
Europe R&D
24
33 VSSD4 S Supply voltage for digital (0 V digital)
34 VDDD4 S Supply voltage for digital 1.8 V digital
35 VDDAFBL S Supply voltage for FBL (1.8 V)
36 VSSAFBL S Supply voltage for FBL (0 V)
37 FBL1 I Fast Blank input 1 (H1) (Analog input)
38 FBL2 I Fast Blank input 2 (H2) (Analog input)
39 RIN1 I R or V in1 (Analog input)
40 GIN1 I G or Y in1 (Analog input)
41 BIN1 I B of U in1 (Analog input)
42 VDDARGB S Supply voltage for RGB (1.8 V)
43 VDDARGB S Supply voltage for RGB (0 V)
44 VDD33RGB S Supply voltage RGB (3.3 V)
45 VDD33RGB S Supply voltage RGB (0 V)
46 RIN2 I R or V in2 (Analog input)
47 GIN2 I G or Y in2 (Analog input)
48 BIN2 I B of U in2 (Analog inpu)
49 VSSD5 S Supply voltage for digital (0 V)
50 VDDAC1 S
Supply voltage CVBS1 (1.8 V) and digital core
supply
51 VSSAC1 S Supply voltage CVBS1 (0 V)
52 CVBS1 I CVBS input (Analog input)
53 CVBS2 I CVBS input (Analog input)
54 CVBS3 I CVBS input (Analog input)
55 CVBS4 I CVBS input or Y1 (Analog input)
56 CVBS5 I CVBS input or C1 (Analog input)
57 CVBS6 I CVBS input or Y2 (Analog input)
58 CVBS7 I CVBS input or C2 (Analog input)
59 VDD33C S Supply voltage CVBS (3.3 V)
60 VSS33C S Supply voltage CVBS (0 V)
61 CVBSO3 O CVBS output 3 (Analog output)
62 CVBSO2 O CVBS output 2 (Analog output)
63 CVBSO1 O CVBS output 1 (Analog output
64 VDDAC2 S Supply voltage CVBS2 (1.8 V)
65 VSSAC2 S Supply voltage CVBS2 (0 V)
66 VDDD1 S Supply voltage for digital (1.8 V digital)
67 VSSD1 S Supply voltage for digital (0 V digital)
68 VDDAPLL S Supply voltage for PLL (1.8 V)
69 XOUT O Crystal connection 2
70 XIN I Crystal connection 1
71 TCLK I Testclock
72 VDDP1 S Supply voltage for digital (3.3 V pad)
73 VSSP1 S Supply voltage for digital (0 V pad)
74 656HIN/CLKF20 I/O Separate H input for 656 / 20.25 clock output
75 VDDDACV S DAC (V)
76 AVOUT O V output
77 VSSDACV S DAC (V)
78 VDDDACU S DAC (U)
79 AUOUT O U output
80 VSSDACU S DAC (U)
