Important Safety Notice
Components Identified by mark have special characteristics inportant for safety.
When replacing any of these components, use only manufacturers specified parts. In case of Ordering these spare parts,
please always add the complete Model-Type number to your order.
LOC PART CODE PART NAME DESCRIPTION REMARK
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ100 PTACPWT2950F ACCESSORY AS DTF-2950FZF-SB
12000 48B5849C1001 TRANSMITTER REMOCON R-49C10
13000 4850Q00910 BATTERY AAA R03 SUPERGARD/ROCKET
14000 4858213801 BAG INSTRUCTION L. D. P. E. T0. 05X250X400
ZZ120 PTBCSHL2950S COVER BACK AS DTL-2950FZF-S
M211 4852174911 COVER BACK 2950 HIPS GY8301A
M211D 4857817610 CLOTH BLACK “300 MM 20”””
M541 4855415800 S/PLATE 150ART P/E FILM (C/TV)
M542 485580002207 LABEL SERIAL ART 90
ZZ130 PTCACAT2950FSS CABINET AS DTF-2950FZS-SB
M201A 4856017752 SCREW CRT FIX 6X35 L120 YL 3CR
M201B 4856219502 WASHER RUBBER CR T2.0 BLACK
M201C 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M201D 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
M201E 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M211A 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M211B 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
M352 2TF01612CL TAPE FILAMENT 12MMX55ME CLEAR
M481 485487071101 BUTTON POWER 2950 GY340A+SV2405BP
M481A 4856716000 SPRING 14Q1/M3 SWPA PIE0.5
M561 48556293SD02 MARK BRAND “DAEWOO 25””29””32”” NEW”
PWC1 4859906210 CORD POWER W/F 6-LO (LOMAX NEW)
SP01A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
SP02A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
V901 4859651760 “CRT (SAMSUNG 29””)” A68QFZ893X002
ZZ131 58G0000194 COIL DEGAUSSING DC-29SF BF AL
ZZ132 48519A7810 CRT GROUND AS 2903S-1015-1P
ZZ200 PTFMSJT2950S MASK FRONT AS DTF-2950FZF-SB
M201 4852092411 MASK FRONT 2950 HIPS GY
ZZ201 PTSPPWT2950F SPEAKER AS DTF-2950FZF-SB
51100 4850704S28 CONN AS YH025-04+35089+ULW=600
SP01 48A8311400 SPEAKER SYSTEM SS-58126F04C
SP02 48A8311400 SPEAKER SYSTEM SS-58126F04C
ZZ280 PTU1MST2950FF PCB UNION MANUAL AS DTF-2950FZF-SB
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV
DL01 DH1L25RS— LED(RED) HI-L25RS
DL02 DH1L25G—- “LED (R,G-3 COLOR)” HI-L25G
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51
HP01 4859105240 JACK PHONO LGT1516-0100
I703 1TS0P4838Y IC PREAMP TSOP34838YA1
JPA3 4859105450 JACK PIN BOARD YSC03P-4120-9S
JPA4 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
LF801 5PLF24A3— FILTER LINE LF-24A3
LF802 58C0000153 COIL CHOKE PFC 6001.0016B
M231 485233251102 PANEL CTRL 2950 ABS GY
M231A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M351 485356811101 HOLDER SENSOR 2950 GY340A(SILVER)
M491 485496331101 BUTTON CTRL 2950 ABS GY
M551 485555530001 DECO SENSOR 2950 GPPS GY9304AT
P702A 4850703N43 CONNECTOR YH025-03+YBH250-03+ULW=500
P703A 4850704S02 CONN AS YH025-04+YST025+ULW=200
P801 4859287320 CONN WAFER MKS2822 (LOMAX NEW TYPE)
P803 4859238620 CONN WAFER YPW500-02
PA01A 4950712003 CONNECTOR YH025-12+YST250+ULW=450
SW801 5S40101146 SW POWER PUSH SS-160-7-B
ZZ200 PTU1JBT2950FF PCB UNION EYE LET AS DTF-2950FZF-SB
E1 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E2 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E3 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E4 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E5 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E6 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E7 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
ZZ200 PTU1JRT2950FF PCB UNION RADIAL AS DTF-2950FZF-SB
C690 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C691 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C770 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
CA21 CCXB1H472K C CERA 50V B 4700PF K (TAPPING)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
Q506 T2SC5343Y- TR 2SC5343Y
Q507 T2SA1980Y- TR 2SA1980Y
SW700 5S50101Z90 SW TACT SKHV10910A
SW701 5S50101Z90 SW TACT SKHV10910A
SW702 5S50101Z90 SW TACT SKHV10910A
SW703 5S50101Z90 SW TACT SKHV10910A
SW704 5S50101Z90 SW TACT SKHV10910A
SW705 5S50101Z90 SW TACT SKHV10910A
Z601 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z602 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z603 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z604 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
ZZ200 PTU1JAT2950FF PCB UNION AXIAL AS DTF-2950FZF-SB
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M (WITH GLUE)
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M (W/O GLUE)
A001 4859816424 PCB UNION 246X246(120X210X2)D1B
C608 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
C609 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA20 CCZB1H472K C CERA 50V B 4700PF K (AXIAL)
DA21 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
DA22 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
J001 85801060GY WIRE COPPER 1/0.6 TIN COATING
L701 5CPZ560K02 COIL PEAKING 56UH 3.5MM K (LAL02TB)
R530 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
R531 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R532 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R533 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R608 RD-2Z151J- R CARBON FILM 1/2 150 OHM J
R609 RD-2Z151J- R CARBON FILM 1/2 150 OHM J
R701 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R721 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R722 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R723 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R724 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R725 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R802 RD-2Z824J- R CARBON FILM 1/2 820K OHM J
RA22 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
ZZ290 PTMPMST2950FS PCB MAIN MANUAL AS DTF-2950FZS-SB
10 2193110001 SOLDER WIRE SN-3.0AG (NP303T) 3.0
20 2193110002 SOLDER WIRE SN-3.0AG-0.5CU (DHB-RMA3)
30 2291050620 FLUX SOLDER DF-2810U (0.810)
40 2291050314 FLUX SOLVENT IM-1000
C315 CEXF2A470V C ELECTRO 100V RSS 47MF (10X16) TP
C402 CMYH3C752J C MYLAR 1.6KV 7500PF J (BUP)
C404 CMYH3C562J C MYLAR 1.6KV 5600PF J (BUP)
C405 CMXE2G243J C MYLAR 400V PU 0.024MF J
C408 CMYE2G184J C MYLAR 400V PU 0.18MF J
C411 CMYF2E105J C MYLAR 250V MPP 1MF J
C415 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C418 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
Caution:In this Service Manual, some parts can be changed for imroving, their performance without notice in the parts list. So, If you
need the latest parts information, please refer to PPL(Parts Price List)in Service information Center(http://svc.dwe.co.kr)
CP-850FX Service Manual
78
Europe R&D
6 SERVICE PARTS LIST
6.1 DTF-2950
