CP-850FX Service Manual
Europe R&D
58
FULL SCREEN 100% 100%
Picture is displayed filling
the full screen (width and
height)
Standard 16/9
picture with 576
active lines
PANORAMA
(not AUTO)
100% 100%
Picture is displayed filling
the full screen (width and
height) by incorporating a
non-linear horizontal
geometrical error
Used to fit a picture
with 4:3 format on a
16:9 screen by
stretching the picture
geometry at the
borders
FAVOURITE
(not AUTO)
100% to
133%
75% to
100%
Customised picture size User-definable
format.
5.3.1.8.2 4:3 CRT
Formats available with 16:9 cathode ray tube;
14:9 (AUTO selectable)
16:9 (AUTO selectable)
FULL SCREEN (AUTO selectable)
WATERGLASS (only available/selectable by the user)
FAVOURITE (only available/selectable by the user)
The table below gives a summary of the FORMAT modes available with a 4:3 CRT, and their
given properties.
Zoom factor – 4:3 CRT
Format Name Vertical Horizontal Description Application
14:9 87% 100%
Picture is centred with
black bars at the top and
bottom of the display,
realised by compressing
the vertical size
14:9 picture – letter
box format with 576
active lines
16:9 75% 100%
Picture is centred with
black bars at the top and
bottom of the display,
realised by compressing
the vertical size
16:9 picture – letter
box format with 576
active lines
FULL SCREEN 100% 100%
Picture is displayed filling
the full screen (width and
height)
Standard 4:3 picture
with 576 active lines
WATERGLASS
(not AUTO)
100% 100%
Picture is displayed filling
the full screen (width and
height) by incorporating a
non-linear horizontal
geometrical error
Used to fit a picture
with 16:9 format on a
4:3 screen by
compressing the
picture geometry at
the borders
FAVOURITE
(not AUTO)
100% to
133%
75% to
100%
Customised picture size User-definable
format.
