4.6 TDA8946J STEREO AUDIO AMPLIFIER
The TDA 8946J is a dual-channel audio power amplifier with an output power of 2 x 15 W at an
8 Ω load and a 18 V supply. The circuit contains two Bridge Tied Load (BTL) amplifiers with an
all-NPN output stage and standby/mute logic. The TDA8946J comes in a 17-pin DIL-bent-
SIL(DBS) power package. The TDA8946J is printed-circuit board compatibel with all other types
in the TDA894x family.
One PCB footprint accommodates both the mono and the stereo products.
4.6.1 FEATURES
Few external components
Fixed gain
Standby and mute mode
No on/off switching plops
Low standby current
High supply voltage ripple rejection
Outputs short-circuit protected to ground, supply and across the load
Thermally protected
Printed-circuit board compatible
Pin description
Pin Symbol Description
1 OUT1- negative loudspeaker terminal 1
2 GND1 ground channel 1
3 Vcc1 supply voltage channel 1
4 OUT1+ positive loudspeaker terminal 1
5 n.c. not connected
6 IN1+ positive input1
7 n.c. not connected
8 IN1- negative input1
9 IN2- negative input2
10 MODE mode selection input
11 SVR half supply voltage decoupling (ripple rejection)
12 IN2+ positive input2
