CP-850/F Service Manual
79
Europe R&D
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
C604 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C805 CEYD2G181D C ELECTRO 400V FHS 180MF
C812 CH1BFE472M C CERA AC AC400V 4700PF M U/C/V
C813 CEXF2E101V C ELECTRO 250V RSS 100MF 18X35.5
C814 CEYF2E470V C ELECTRO 250V RSS 47MF (16X25
C820 CCXR3D221K C CERA 2KV R 220PF K125C
C823 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP
C840 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C861 CEXF1E102C C ELECTRO 25V RUS 1000MF 13X20 TP
C899 CMXF2J333J C MYLAR 630V MPP 0.033MF J
CP01 CMYF2G224J C MYLAR 400V MPU 0.22MF J
CP02 CMXE2J222J C MYLAR 630V PU 2200PF
CP04 CEXF1H221V C ELECTRO 50V RSS 220MF (10X16) TP
CP07 CMYF2J154J C MYLAR 630V MPP 0.15MF J
D401 DDTV1500MD DIODE DTV1500MD TO-220AC01
D404 DFMP3FU—- DIODE FMP3FU
D404A 4857027603 HEAT SINK AL EX
D404B 7174301051 SCREW TAPPTITE TT2 RND 3X10 MFZN 3CR
D406 DRGP30J—- DIODE RGP30J
D820 DRGP30J—- DIODE RGP30J
D860 DRGP30J—- DIODE RGP30J
D870 DRGP30J—- DIODE RGP30J
I301 1TDA8358J- IC VERTICAL TDA8358J
I301A 4857028219 HEAT SINK AL EX ANODIZING
I301B 7174301051 SCREW TAPPTITE TT2 RND 3X10 MFZN 3CR
I601 1MSP3410V3 IC SOUND MSP3410G-V3
I602 1TDA8946J- IC AUDIO TDA8946J
I602A 4857028215 HEAT SINK AL EX NO ANODOZING
I602B 7174301051 SCREW TAPPTITE TT2 RND 3X10 MFZN 3CR
I701 1SDA555XFL IC MICOM OTP SDA555XFL/PO
I702 1M24C16BN6 IC MEMORY M24C16WRN6
I801 1STRW6754- IC POWER STR-W6754
I801A 4857024600 HEAT SINK AL EX B/K
I801B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I804 1LTV817C— IC PHOTO COUPLER LTV-817C
I806 1DP125—— IC ERROR AMP DP125
I820 1S7805P1C- IC REGULATOR S7805PIC 5.0V 1.0A
I821 1K78R33—- IC REGULATOR KIA78R33AP
I822 1K78R08—- IC REGULATOR KIA78R08API
I822A 4857026900 HEAT SINK AL EX
I822B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I824 1K78R018P1 IC REGULATOR KIA78R018PI
I825 1K78R05—- IC REGULATOR KIA78R05PI
I826 1A1117P133 IC REGULATOR KIA1117PI33 3.3V TO-220IS
JPA1 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA2 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
L150 58E0000041 COIL AFT TRF-A005
L401 58H0000054 COIL H-LINEARITY TRL-040F
L403 58C0000130 COIL CHOKE CH-161A
P401 4850705S04 CONN AS YH025-05+YST025+ULW=400
P402 4859242420 CONN WAFER YFW800-04
P404 4859242220 CONN WAFER YFW800-02
P501 4850708N15 CONNECTOR YH025-08+YBNH250+USW=600
P601 4859231720 CONN WAFER YW025-04
P702 4859231620 CONN WAFER YW025-03
P703 4859231720 CONN WAFER YW025-04
P802 4859242220 CONN WAFER YFW800-02
P804 4859238620 CONN WAFER YPW500-02
PA01 4859235520 CONN WAFER YW025-12
Q401 TST2310DH1 TR ST2310DHI
Q401A 4857033201 HEAT SINK AL EX BK (ANODIZING)
Q401B 7174301051 SCREW TAPPTITE TT2 RND 3X10 MFZN 3CR
Q807 TKTA1659AY TR KTA1659AY
QP03 T1RF640N— FET IRF640NPBF
QP03A 4857026900 HEAT SINK AL EX
QP03B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
R388 RW02Y678FS R WIRE WOUND 2W 0.67 OHM F SMALL
R399 RS02Y829JS R M-OXIDE FILM 2W 8.2 OHM J SMALL
R407 RF01Y129JA R FUSIBLE 1W 1.2 OHM J A CURVE
R444 RS02Y330JS R M-OXIDE FILM 2W 33 OHM J SMALL
R801 DJ5020M270 POSISTOR J502P72D070M270
R803 RS02Y338JS R M-OXIDE FILM 2W 0.33 OHM J SMALL
R806 RS02Y228JS R M-OXIDE FILM 2W 0.22 OHM J SMALL
R819 RX07B339JP R CEMENT 7W 3.3 OHM J BEN 15MM 4P
R841 RS02Y309JS R M-OXIDE FILM 2W 3 OHM J SMALL
R850 RS02Y569JS R M-OXIDE FILM 2W 5.6 OHM J SMALL
R852 RS02Y569JS R M-OXIDE FILM 2W 5.6 OHM J SMALL
R854 RS02Y569JS R M-OXIDE FILM 2W 5.6 OHM J SMALL
R885 RS02Y339JS R M-OXIDE FILM 2W 3.3 OHM J SMALL
R899 RS02Y683J- R M-OXIDE FILM 2W 68K OHM J
SF1 5PK3953M— FILTER SAW K3953M
SF2 5PK9650M— FILTER SAW K9650M
T401 50D25A2—- TRANS DRIVE TD-25A2
T402 50H0000317 FBT 1372.0136
T801 50M4818A2- TRANS SMPS 2094.0119
U100 4859724930 TUNER VARACTOR UV1316/AI-4
X501 5XE20R250E CRYSTAL QUARTZ HC-49/U 20.2500MHZ 30PPM
X601 5XE18R432E CRYSTAL QUARTZ HC-49/U 18.43200MHZ 30PPM
Y801 5SC0101003 SW RELAY DG12D1-0(M)-II 1C-1P
Z153 5PXXT5R5MB FILTER CERA XT 5.5MB (TAPPING)
ZZ200 PTMPJBT2950FS PCB MAIN EYE LET AS DTF-2950FZS-SB
E1 4856310600 EYE LET BSR 2.3(R2.3) BIG
E10 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E11 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E12 4856310600 EYE LET BSR 2.3(R2.3) BIG
E13 4856310600 EYE LET BSR 2.3(R2.3) BIG
E14 4856310600 EYE LET BSR 2.3(R2.3) BIG
E15 4856310600 EYE LET BSR 2.3(R2.3) BIG
E16 4856310600 EYE LET BSR 2.3(R2.3) BIG
E17 4856310600 EYE LET BSR 2.3(R2.3) BIG
E18 4856310600 EYE LET BSR 2.3(R2.3) BIG
E19 4856310600 EYE LET BSR 2.3(R2.3) BIG
E2 4856310600 EYE LET BSR 2.3(R2.3) BIG
E20 4856310600 EYE LET BSR 2.3(R2.3) BIG
E21 4856310600 EYE LET BSR 2.3(R2.3) BIG
E22 4856310600 EYE LET BSR 2.3(R2.3) BIG
E23 4856310600 EYE LET BSR 2.3(R2.3) BIG
E24 4856310600 EYE LET BSR 2.3(R2.3) BIG
E25 4856310600 EYE LET BSR 2.3(R2.3) BIG
E26 4856310600 EYE LET BSR 2.3(R2.3) BIG
E27 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E28 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E29 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E3 4856310600 EYE LET BSR 2.3(R2.3) BIG
E30 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E31 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E32 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E33 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E34 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E35 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E36 4856310600 EYE LET BSR 2.3(R2.3) BIG
E37 4856310600 EYE LET BSR 2.3(R2.3) BIG
E38 4856310600 EYE LET BSR 2.3(R2.3) BIG
E39 4856310600 EYE LET BSR 2.3(R2.3) BIG
E4 4856310600 EYE LET BSR 2.3(R2.3) BIG
E40 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E41 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E42 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E43 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E48 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E49 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E5 4856310600 EYE LET BSR 2.3(R2.3) BIG
E50 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E51 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E52 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E53 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E54 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E56 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E57 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
