CP-850FX Service Manual
Europe R&D
28
48 VRD/BCS I DAC Reference, Beam current safety
49 AGND S Analog Ground for Analog Matrix
50 FBLIN1 I Fast Blank1input
51 RIN1 I Analog Red1input
52 GIN1 I Analog Green1 input
53 BIN1 I Analog Blue1input
54 FBLIN2 I Fast Blank2 input
55 RIN2 / P
R
I Analog Red2 input / P
R
Input
56 GIN2 / Y I Analog Green2 input / Y Input
57 BIN2/ P
B
I Analog Blue2 input / P
B
Input
58 ASG2 S Analog Shield Ground
59 HCS I Half Contrast
60 NC
61 TEST I
62 RESQ I Reset Input, active low
63 SCL I/O I
2
C Bus clock
64 SDA I/O I
2
C Bus data
65 C0 I Picture Bus Chroma (LSB)
66 C1 I Picture Bus Chroma
67 C2 I Picture Bus Chroma
68 C3 I Picture Bus Chroma
69 C4 I Picture Bus Chroma
70 C5 I Picture Bus Chroma
71 C6 I Picture Bus Chroma
72 C7 I Picture Bus Chroma (MSB)
73 VSUPD S Supply voltage, Digital Circuitry
74 GNDD S Ground, Digital Circuitry
75 Y0 I Picture Bus Luma (LSB)
76 Y1 I Picture Bus Luma
77 Y2 I Picture Bus Luma
78 Y3 I Picture Bus Luma
79 Y4 I Picture Bus Luma
80 Y5 I Picture Bus Luma
