CP-850FX Service Manual
Europe R&D
32
23 NC Not Connected
24 RESETQ In Power-On-reset
25 DACA_R Out Headphone out right
26 DACA_L Out Headphone out left
27 VREF2 Reference ground 2 high voltage part
28 DACM_R Out Loudspeaker out Right
29 DACM_L Out Loudspeaker out Left
30 NC Not Connected
31 NC Not Connected
32 NC Not Connected
33 SC2_OUT_R Out Scart output 2 right
34 SC2_OUT_L Out Scart output 2 left
35 VREF1 Reference ground 1 high voltage part
36 SC1_OUT_R Out Scart output 1, right
37 SC1_OUT_L Out Scart output 1, left
38 CAPL_A Volume capacitor AUX
39 AHVSUP Analog power supply 8.0V
40 CAPL_M Volume capacitor MAIN
41 AHVSS Analog ground
42 AGNDC Analog reference voltage high voltage part
43 NC Not Connected
44 NC Not Connected
45 NC Not Connected
46 SC3_IN_L In Scart input 3 in, left
47 SC3_IN_R In Scart input 3 in, right
48 ASG2 Analog Shield Ground 2
49 SC2_IN_L In Scart input 2 in, left
50 SC2_IN_R In Scart input 2 in, right
51 ASG1 Analog Shield Ground 1
52 SC1_IN_L In Scart input 1 in, left
53 SC1_IN_R In Scart input 1 in, right
54 VREFTOP Reference voltage IF A/D converter
55 MONO_IN In Mono input
56 AVSS Analog ground
57 AVSUP Analog power supply
58 ANA_IN1+ In IF input 1
59 ANA_IN1- In IF common
60 NC Not Connected
61 TESTEN In Test pin
62 XTAL_IN In Crystal oscillator
63 XTAL_OUT Out Crystal oscillator
64 NC Test pin
