CP-850/F Service Manual
81
Europe R&D
LOC PART CODE PART NAME DESCRIPTION REMARK
LOC PART CODE PART NAME DESCRIPTION REMARK
RC580 HRFT821JBA R CHIP 1/10 820 OHM J 1608
RC581 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC582 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC583 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC584 HRFT821JBA R CHIP 1/10 820 OHM J 1608
RC585 HRFT911JBA R CHIP 1/10 910 OHM J 1608
RC586 HRFT911JBA R CHIP 1/10 910 OHM J 1608
RC587 HRFT821JBA R CHIP 1/10 820 OHM J 1608
RC589 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC591 HRFT393JBA R CHIP 1/10 39K OHM J 1608
RC595 HRFT271JBA R CHIP 1/10 270 OHM J 1608
RC598 HRFT271JBA R CHIP 1/10 270 OHM J 1608
RC611 HRFT224JBA R CHIP 1/10 220K OHM J 1608
RC661 HRFT512JBA R CHIP 1/10 5.1K OHM J 1608
RC662 HRFT512JBA R CHIP 1/10 5.1K OHM J 1608
RC701 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC708 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
RC715 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC716 HRFT113JBA R CHIP 1/10 11K OHM J 1608
RC725 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC729 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC730 HRFT223JBA R CHIP 1/10 22K OHM J 1608
RC731 HRFT223JBA R CHIP 1/10 22K OHM J 1608
RC732 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC733 HRFT473JBA R CHIP 1/10 47K OHM J 1608
RC737 HRFT682JBA R CHIP 1/10 6.8K OHM J 1608
RC738 HRFT000-BA R CHIP 1/10 0 OHM 1608
RC739 HRFT000-BA R CHIP 1/10 0 OHM 1608
RC740 HRFT000-BA R CHIP 1/10 0 OHM 1608
RC741 HRFT682JBA R CHIP 1/10 6.8K OHM J 1608
RC742 HRFT682JBA R CHIP 1/10 6.8K OHM J 1608
RC743 HRFT682JBA R CHIP 1/10 6.8K OHM J 1608
RC750 HRFT183JBA R CHIP 1/10 18K OHM J 1608
RC770 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
RC799 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
RC881 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC882 HRFT103JBA R CHIP 1/10 10K OHM J 1608
ZZ200 PTMPJRT2950FS PCB MAIN RADIAL AS DTF-2950FZS-SB
C102 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C106 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C117 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C118 CMXL1J474J C MYLAR 63V 0.47MF MKT
C120 CXRH1H150J C CERA 50V RH 15PF J (TAPPING)
C121 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C150 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C152 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C153 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C157 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C164 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C188 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C301 CMXM2A224J C MYLAR 100V 0.22MF J
C305 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C313 CMXM2A104J C MYLAR 100V 0.1MF J TP
C320 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C340 CMXM2A683J C MYLAR 100V 0.068MF J TP
C350 CMXM2A223J C MYLAR 100V 0.022MF J TP
C351 CMXM2A223J C MYLAR 100V 0.022MF J TP
C370 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
C401 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C410 CCXB2H681K C CERA 500V B 680PF K (TAPPING)
C416 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C417 CMXM2A392J C MYLAR 100V 3900PF J TP
C420 CMXM2A273J C MYLAR 100V 0.027MF J TP
C424 CMXM2A333J C MYLAR 100V 0.033MF J TP
C425 CCXB1H472K C CERA 50V B 4700PF K (TAPPING)
C501 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C502 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C503 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C504 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C505 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C506 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C524 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C530 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C550 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C551 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C560 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C561 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C568 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C590 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C602 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C605 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C608 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C610 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C611 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C612 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C613 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C614 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C615 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C616 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C623 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C624 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C625 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C626 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C627 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C630 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C634 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C636 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C641 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C642 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C660 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C661 CMXM2A224J C MYLAR 100V 0.22MF J
C662 CMXM2A224J C MYLAR 100V 0.22MF J
C666 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C668 CMXM2A224J C MYLAR 100V 0.22MF J
C669 CMXM2A224J C MYLAR 100V 0.22MF J
C709 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C711 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C713 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C730 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C733 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C737 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C742 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C744 CEXF1E100V C ELECTRO 25V RSS 10MF TP
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C806 CCXR3A102K C CERA 1KV R 1000PF (T) 125C
C807 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C810 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C811 CMXM2A473J C MYLAR 100V 0.047MF J TP
C830 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C831 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C833 CCXB1H821K C CERA 50V B 820PF K (TAPPING)
C835 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C845 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C846 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C847 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C850 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C853 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C854 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C863 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C864 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C865 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C866 CCXR3A471K C CERA 1KV R 470PF K 125C
C871 CEXF1C471V C ELECTRO 16V RSS 470MF (10X12.5)TP
C880 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C888 CEXF1E220V C ELECTRO 25V RSS 22MF TP
CP05 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP06 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
I704 1K1A7025AP IC RESET KIA7025AP
L101 5CPX479K— COIL PEAKING 4.7UH K RADIAL
L380 58C0000116 COIL BEAD HC-3550R
L381 58C0000116 COIL BEAD HC-3550R
