5. TROUBLE SHOOTING GUIDE
Concerning Wash
Problem
Check Point
Cause
Solution
Pulsator does
not rotate.
Is the Power properly connected?
Is the Motor hot?
(In case there is Thermal Protector)
Is the Wiring good?
(Refer to the Wiring Diagram)
Is the contact of Wash Timer good?
Is the Condenser properly
connected?
Motor does not start due
to opening the Condenser
circuit.
Reconnect the Power Cord.
Reconnect the Condenser.
Power restored when
Motor cools
Power has been cut off
by the Thermal Protector
Improper wiring.
Defective Wash Timer.
Defective Wash Motor.
Defect of mechanical
assembly.
Reconnect the wiring.
Replace Wash Timer.
Replace Wash Motor.
Tighten the screws fixed
on the Pulley.
Replace V-Belt
Remove impurities after
disassembling pulsator.
Replace Case Shaft As..
Replace pulsator.
Reload with proper wash
load.
Is there a whirring sound from the
Wash Motor when turned on?
NO
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
Pulsator does not
rotate smoothly.
Is the wash load appropriate?
Are the Pulsator and Motor Pulley
securely assembled?
Does the V-Belt slip?
Are there impurities between the
Pulsator and Tub.
Does the pulsator shaft rotate propely
when the pulsator has been
disassembled?
Worn out the Serration
within the pulsator.
Defective Case Shaft As.
Worn out V-Belt.
Revolution obstructed by
impurities.
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
Note :
Pull out the power plug prior repair and make sure that the Washing machine has been
properly grounded.
