GEAR MECHANISM ASS'Y
The proper water currents is made by the rotation of pulsator at a low speed (about 145 r.p.m) to prevent the damage to
the small sized clothes.
PRINCIPLE OF BUBBLE GENERATOR
STRUCTURE
8
Pulsator shaft
Inner clutch spring
Brake lever
Spinner shaft
Planetary gear
Clutch spring
Clutch boss
Spinner pulley
Sun gear
Internal gear
Planetary gear
Pulsator
Planetary
V-belt
Spinner
pulley
1 revolution
5.2 revolutions
Motor
Motor
V.belt
Planetary
Gear
Directly
Spinner Pulley
775 r.p.m.
Pulsator
145 r.p.m.
Tub
775 r.p.m.
1490 r.p.m.
60(Hz)
1/5.2
Bobbin & coil
Trans core
Magnet
Armature
Bellows
Air out hole
Protector A
Protector B
Air in hole
Air
Air
