Daewoo G424E - N2001 Regulator Disassembly Steps

G420E/G424E Tier LP Engine N2001 Regulator/Converter 67
N2001 Regulator
Disassembly Steps:
1. Remove the six secondary cover screws (1), the
secondary cover (2) and the secondary
diaphragm (3).
2. Remove the six primary diaphragm cover screws
(4) and the primary cover assembly (5).
3. Remove the six primary diaphragm cover screws
(4) and the primary cover assembly (5).
4. Remove the primary diaphragm by sliding the
diaphragm to one side, releasing the primary
valve pin (Figure R6).
Figure R3
Figure R4
Figure R5
Figure R5
Figure R6
1
2
3
4
5
