Operation Section
-120-
Lift Fork Adjustment
WARNING
When adjusting the fork spread, be careful not
to pinch your hand between forks and the
carriage slot.
Hook-on type Fork
1. Move up the hook pin to the free position.
2. Raise the hook pin in each fork to side the fork
on the carriage bar.
3. Adjust the forks in the position most appropriate
for the load and as wide as possible for load
stability.
4. When adjusting the forks, make sure that the
weight of the load is centered on the truck.
5. After adjustment, set the fork locks to keep the
forks in place.
WARNING
Make sure the forks are locked before carrying
a load.
To Next Page
