Operation Section
-71-
Tilt Control
1. Mast Tilt Forward - Push the lever
FORWARD smoothly to tilt the mast
forward.
2. Mast Hold - When the lever is released it
will return to the HOLD or center position.
Tilting action will stop.
3. Mast Tilt Back - Pull the lever BACK
smoothly to tilt the mast backward.
Sideshift Attachment (If Equipped)
1. Sideshift Left - Push the lever
FORWARD to shift the carriage to the left.
2. Sideshift Hold - When the lever is
released it will return to the HOLD or
center position. Sideshifting action will
stop.
3. Sideshift Right - Pull the lever BACK to
shift the carriage to the right.
