7
11
Door latch - When the door is closed it will
automatically shut off. If the door is opened
while the oven is operating, the magnetron
will automatically shut off.
22
Door seal - The door seal maintains the
microwave within the oven cavity and
prevents microwave leakage.
33
Oven cavity
44
Spatter shield - Protects the microwave
outlet from splashes of cooking foods.
55
Safety interlock system - Prevents the oven
from operating while the door is opened.
66
Door release button - Pushing this button
stops oven operation and opens the door.
77
Glass cooking tray - Made of special heat
resistant glass. The tray must always be in
proper position before operating.
Do not cook food directly on the tray.
88
Roller guide - Supports the glass cooking tray.
99
Door screen - Allows viewing of food.
The screen is designed so that light can pass
through, but not the microwaves.
00
Toaster drawer
qq
Toaster opening handle
ww
Crumb Tray(refer. page10)
FEATURES DIAGRAM
