1. To remove cabinet
1) Remove four screws on cabinet back.
2) Pull the cabinet backward.
2. To remove door assembly
1) Remove the 'STOPPER DOOR' from the door assembly.
2) Open the door assembly at a right angle.
3) Reverse the above for reassembly.
NOTE : After replacing the door assembly, perform a check of correct alignment with the hinge and cavity front plate.
